psp ghetto joystick

[joesnose]

I have a device and it seems to have a Mini USB Jack at the end of it will it work. I opened it and the Jack is solder right into the circuit board with no wires seen anywhere so would 1 have to lead my own wire.

should work, i had to solder wires to my port.

[findol]

hey joe can you upload/send me a tuturial with some close up shots? i downloaded 1 earlier but the pics were way 2 small, Anbd how did you make the cool mounting unit?


thanks

nice mods btw!

[joesnose]

hey joe can you upload/send me a tuturial with some close up shots? i downloaded 1 earlier but the pics were way 2 small, Anbd how did you make the cool mounting unit?


thanks

nice mods btw!

if you double click the images they should enlarge

[findol]

yeh they do its jus i need a photo of the usb wiring. i have all wires soldered to the analouge stick. and i have the usb ready

could you send a pic of the usb male and female wiring?

thanks

[findol]

also joe how did you make thatsweet casing for the madcatz version of the stick???

thanks

[findol]

also could you make like a template for the mounting and upload it that would be smart

cheers

[mavsman4457]

OK Joe thank you very much. He estimated that it would be done in only a couple of days and it's taken almost two weeks. I'm kind of getting anxious so if you get any updates from him could you post them here too?

[Avi]

@findol: for the casing he used Milliput which is used to patch up leaks in drains in stuff. Works really well.

[joesnose]

yeh they do its jus i need a photo of the usb wiring. i have all wires soldered to the analouge stick. and i have the usb ready

could you send a pic of the usb male and female wiring?

thanks

im sorry dude, i was never planning on a tutorial i didnt realy take note of which wire went where, i wired the nub to the female usb, then plugged the male one in an used my multimeter to find out which was which. i used this tutorial from ben heck:http://www.engadget.com/2006/10/10/h...your-sony-psp/
but i had to turn the controller through 90 degrees so the side where the switch was faced the psp

[joesnose]

also could you make like a template for the mounting and upload it that would be smart

cheers

the mounting on the ghetto stick is just two peices of aluminium cut from a bracket from the inside of a pc, and a whole lot of hotglue, ghetto.
